ESAB Cutmaster 60 - APPENDIX 2: DATA TAG INFORMATION

ESAB CUTMASTER 60
APPENDIX Manual 0-5402
A-2
U0=
I
X
U
2
S
U1
I1max I1eff
3ø
3ø
f
1
f
2
3 ~
Model:
Date of Mfr:
Type of Power
Supply (Note 1)
Manufacturer's Name and/or
Logo, Location, Model and
Revision Level, Serial Number
and Production Code
Regulatory Standard Covering
This Type of Power Supply
Plasma Cutting
Symbol
Output Current Type
Duty Cycle Factor
Rated No-
Load Voltage
Conventional
Load Voltage
Rated Maximum
Supply Current
Maximum Effective
Supply Current
Output Range (Amperage/
Voltage)
Duty Cycle Data (Note 3)
Input Power
Symbol
Input Power
Specifications
(Phase, AC or DC
Hertz Rating)
Degree of
Protection
Rated Supply
Voltage (Note 2)
Manufacturer's Electrical
Schematic File Number
and Revision Level
NOTES:
1. Symbol shown indicates three-phase AC input, static
frequency converter-transformer-rectifier, DC output.
2. Indicates input voltages for this power supply. Most power
supplies carry a label at the input power cord showing input
voltage requirements for the power supply as built.
3. Top row: Duty cycle values.
IEC duty cycle value is calculated as specified by
the International ElectroTechnical Commission.
Duty cycle value is determined under the power supply
manufacturer's test procedures.
Second row: Rated cutting current values.
Third row: Conventional load voltage values.
4. Sections of the Data Tag may be applied to separate areas
of the power supply.
S/N
Standard Symbols
Ø
AC
DC
Phase
Art # A-12784_AA
APPENDIX 2: DATA TAG INFORMATION
