66
Attention: Turn the power switch off and wait until the lamp has cooled down before
touching it.
1. Loosen the screw (a) on the left side of the
sewing head and remove the face plate (b).
2. If the machine is equipped with a 5W lamp,
replace the bulb as follows:
Pull light bulb downward to remove.
Replace the bulb with same type rated 5W.
Replace the face plate and tighten the
screw.
REPLACING THE LIGHT BULB
REPLACING THE LIGHT BULB
1
a
b
Please Note:
-
-
The 5W lamp is user-replaceable.
The 240mW LED lamp is not user-replaceable.
3
2
PUSH
3. If the machine is equipped with a 240mW
LED lamp, you must contact the
manufacturer or its service agent for repair
in the event of failure.
