FUSE BOX LOCATIONS
Engine compartment fuse box
This fuse box is located in the engine
compartment See Maintenance (page
184).
Passenger compartment fuse
box
1. Pinch the retaining clips to release the
cover.
2. Lower the fuse box cover and pull it
towards you.
Install in the reverse order.
Load compartment fuse box
CHANGING A FUSE
WARNINGS
Do not modify the electrical system
of your vehicle in any way. Have
repairs to the electrical system and
the replacement of relays and high current
fuses carried out by a properly trained
technician.
Switch the ignition and all electrical
equipment off before touching or
attempting to change a fuse.
CAUTION
Fit a replacement fuse with the same
rating as the one you have removed.
Note:
You can identify a blown fuse by
a break in the filament.
Note:
All fuses, except high current
fuses, are a push fit.
Note:
A fuse puller is located in the
engine compartment fuse box.
173
Fuses
