1. Press the locking buttons together.
2. Rotate and remove the wiper blade.
Note:
Make sure that the wiper blade
locks into place.
3. Install in the reverse order.
Rear window wiper blade
1. Lift the wiper arm.
2. Slightly rotate the wiper blade from the
wiper arm.
3. Disengage the wiper blade from the
wiper arm.
4. Remove the wiper blade.
Note:
Make sure that the wiper blade
locks into place.
5. Install in the reverse order.
TECHNICAL SPECIFICATIONS
Windscreen wiper blade lengths
Dimension in mm (inches)
Passenger sideDriver side
630 (24.8)730 (28.7)
56
Wipers and washers
