REFUELING
WARNINGS
Do not attempt to start the engine if
you have filled the fuel tank with the
incorrect fuel. This could damage the
engine. Have your vehicle checked by an
authorized dealer immediately.
Do not use any kind of flames or heat
near the fuel system. The fuel system
is under pressure. There is a risk of
injury if the fuel system is leaking.
If you use a high pressure spray to
wash your vehicle, only spray the fuel
filler flap briefly from a distance not
less than 8 inches (200 millimeters).
We recommend that you wait at
least 10 seconds before removing the
fuel nozzle to allow any residual fuel
to drain into the fuel tank.
Stop refueling after the fuel nozzle
stops the second time. Additional
fuel will fill the expansion space in
the fuel tank which could lead to fuel
overflowing. Fuel spillage could be
hazardous to other road users.
Do not remove the fuel nozzle from
its fully inserted position during the
entire refueling process.
Note: Your vehicle does not have a fuel filler
cap.
1. Press the flap to open it. Open the flap
fully until it engages.
Note: When you insert the correct size fuel
nozzle, a spring loaded inhibitor will open.
This helps to avoid filling up with the
incorrect fuel.
2. Insert the fuel nozzle up to and
including the first notch on the fuel
nozzle A. Keep it resting on the cover
of the fuel pipe opening.
119
Kuga (CBS) Vehicles Built From: 10-03-2014, Vehicles Built Up To: 31-12-2014, CG3585en enGBR, Edition date: 02/2014, None
Fuel and Refueling
