• Vehicle speed falls below 16 mph (25
km/h).
• The camera sensor is too hot or
becomes blocked.
Switching the System On
Switch the system on using the information
display. See Information Displays (page
68).
Turn the switch to the autolamps position.
See Autolamps (page 50).
The indicator will illuminate to
confirm when the system is
ready to assist.
Note: The indicator will only illuminate
when it is dark and headlamps have been
switched on.
Note: The system may take a short time to
initialize after first switching the ignition on,
especially in very dark conditions. The high
beam will not automatically switch on
during this time.
Setting the System Sensitivity
The system has three sensitivity levels
which can be accessed via the information
display. See Information Displays (page
68).
The set level determines the speed at
which the high beam will be restored after
detected traffic leaves the field of view.
Manually Overriding the System
Push or pull the lever to switch between
high and low beam.
Note: This is a temporary override and the
system will return to automatic operation
after a short period.
To permanently switch the system off, use
the information display menu or turn the
lighting control switch to the headlamps
position.
FRONT FOG LAMPS
Press the control to switch the fog lamps
on or off.
You can switch the fog lamps on when the
lighting control is in any position except
off.
52
Kuga (CBS) Vehicles Built From: 10-03-2014, Vehicles Built Up To: 31-12-2014, CG3585en enGBR, Edition date: 02/2014, None
Lighting
