Fuji Electric FRENIC-Lift LM2A Series User Manual

7-1
Chapter 7 SPECIFICATIONS
7.1 Standard Model
1) Three-phase 400V series
Item
Specifications
Type FRN___LM2A-4□
0006
0010
0015
0019
0025
0032
Nominal applied motor [kW]
2.2
4.0
5.5
7.5
11
15
Output ratings
Rated capacity
*1
[kVA]
4.6
7.6
11
14
18
24
Rated voltage
*2
[V]
Three-phase 380V-480V, 50/60Hz
Rated current
*3
[A]
6.1
10.0
15.0
18.5
24.5
32.0
Overload capacity [A]
(Permissible overload time)
11.0
(3s)
18.0
(3s)
27.0
(3s)
37.0
(3s)
49.0
(3s)
64.0
(3s)
Rated frequency [Hz]
50, 60Hz
 Input ratings
Main power supply
Normal operation
Phases, Voltage, Frequency
Three-phase, 380 to 480V, 50/60Hz
Variations
Voltage: +10 to -15% (Voltage unbalance: 2% or less
*4
)
Frequency: +5 to -5%
Rated
current
*5
[A]
with DCR
4.5
7.5
10.6
14.4
21.1
28.8
Without DCR
8.2
13
17.3
23.2
33.0
43.8
Required power supply capacity
(with DCR) [kVA]
3.2
5.2
7.4
10
15
20
UPS operation
Phases,Voltage,Frequency
Single-phase, 220 to 480V, 50/60Hz
Variations
Voltage: +10 to -10% ,Frequency: +5 to -5%
Operation time [s]
180
Battery operation
Power Supply Voltage for driving
DC 48V or more in the direct current voltage conversion.
Operation time [s]
180
Auxiliary control power supply Voltage
DC 24V (22V to 32V) ,Maximum 40W
Braking
Braking time
*7
[s]
60
Braking duty-cycle (%ED)
*7
[%]
50
Rated regenerative power
*7
[kW]
1.8
3.2
4.4
6.0
8.8
12
Minimum resistance which can be
connected [Ω]
*6
160
96
47
47
24
24
EMC filter
Built-in (According to EN12015, EN12016)
Enclosure (IEC60529)
IP20
Heat sink
IP54
Cooling method
Fan cooling
Average sound pressure level
at trip.[dBA]
*8
44.5
48
49.5
Average power losses [W]
in standstill
*12
23
26
in standby
*13
16
Weight/Mass [kg]
4.4
4.4
4.7
4.7
6.1
6.3
