FujiFilm X-T20 User Manual

140
6
The Shooting Menus
AF+MF
If ON is selected in focus mode S, focus can be ad-
justed manually by rotating the focus ring while the
shutter button is pressed halfway. Both standard and
focus peaking MF assist options are supported.
Options
Options
ON OFF
O
Lenses with a focus distance indicator must be set to
manual focus mode (MF) before this option can be used.
Selecting MF disables the focus distance indicator. Set
the focus ring to the center of the focus distance indi-
cator, as the camera may fail to focus if the ring is set to
in nity or the minimum focus distance.
AF + MF Focus Zoom
When ON is selected for G AF/MF SETTING> FOCUS CHECK
and SINGLE POINT selected for AF MODE, focus zoom can
be used to zoom in on the selected focus area. The zoom ra-
tio (2.5× or 6×) can be selected using the rear command dial.

FujiFilm X-T20 Specifications

General

Megapixels	24.3 MP
ISO Range	200-12800 (expandable to 100-51200)
Continuous Shooting Speed	8 fps
Weight	383 g (including battery and memory card)
Image Processor	X-Processor Pro
Wireless Connectivity	Wi-Fi
Battery	NP-W126S Li-ion battery
Dimensions	118.4 x 82.8 x 41.4 mm
Sensor	APS-C X-Trans CMOS III
Autofocus Points	91 points
Screen	3.0-inch tilting LCD (1.04M dots)
Viewfinder	0.39-inch OLED (2.36M dots)
Video Resolution	4K at 30 fps, Full HD at 60 fps
Battery Life	Approx. 350 shots
Shutter Speed	1/4000 sec to 30 sec
