FujiFilm X-T20 User Manual

257
Peripherals and Optional Accessories
10
External Flash Units
Flash Settings
To adjust settings for a  ash unit mounted on the hot
shoe or connected via the sync terminal:
1
Connect the unit to the camera.
2
In shooting mode, select FLASH
FUNCTION SETTING in the F
(FLASH SETTING) menu tab.
The options available vary with
the  ash unit.
Menu
Menu
Description
Description
P
P
Built-In
Flash
Displayed when the built-in fl ash is raised. 107
SHOE
MOUNT
FLASH
Displayed when an optional fl ash unit is
mounted on the hot shoe and turned on.
262
MASTER
(OPTICAL)
Displayed if an optional fl ash unit functioning as
a master fl ash for FUJIFILM optical wireless re-
mote fl ash control is connected and turned on.
266
O
SYNC TERMINAL is displayed if the built-in  ash is
lowered and either no  ash unit, or an incompatible
 ash unit, is mounted on the hot shoe.
EXIT
FLASH SETTING
RED EYE REMOVAL
TTL-LOCK MODE
FLASH FUNCTION SETTING
LED LIGHT SETTING
MASTER SETTING
CH SETTING

FujiFilm X-T20 Specifications

General

Megapixels	24.3 MP
ISO Range	200-12800 (expandable to 100-51200)
Continuous Shooting Speed	8 fps
Weight	383 g (including battery and memory card)
Image Processor	X-Processor Pro
Wireless Connectivity	Wi-Fi
Battery	NP-W126S Li-ion battery
Dimensions	118.4 x 82.8 x 41.4 mm
Sensor	APS-C X-Trans CMOS III
Autofocus Points	91 points
Screen	3.0-inch tilting LCD (1.04M dots)
Viewfinder	0.39-inch OLED (2.36M dots)
Video Resolution	4K at 30 fps, Full HD at 60 fps
Battery Life	Approx. 350 shots
Shutter Speed	1/4000 sec to 30 sec
