FujiFilm X-T20 User Manual

17
1
Before You Begin
Camera Displays
Customizing the Standard Display
To choose the items shown in the standard display:
1
Display standard indicators.
Use the DISP/BACK button to display standard in-
dicators.
2
Select DISP. CUSTOM SETTING.
Select D SCREEN SETTING> DISP. CUSTOM SET-
TING in the setup menu.
3
Choose items.
Highlight items and press MENU/OK to select or
deselect.
•
FRAMING GUIDELINE
•
ELECTRONIC LEVEL
•
FOCUS FRAME
•
AF DISTANCE INDICATOR
•
MF DISTANCE INDICATOR
•
HISTOGRAM
•
SHOOTING MODE
•
APERTURE/S-SPEED/ISO
•
INFORMATION
BACKGROUND
•
Expo. Comp. (Digit)
•
Expo. Comp. (Scale)
•
FOCUS MODE
•
PHOTOMETRY
•
SHUTTER TYPE
•
FLASH
•
CONTINUOUS MODE
•
DUAL IS MODE
•
TOUCH SCREEN MODE
•
WHITE BALANCE
•
FILM SIMULATION
•
DYNAMIC RANGE
•
FRAMES REMAINING
•
IMAGE SIZE/QUALITY
•
MOVIE MODE & REC. TIME
•
BATTERY LEVEL
•
FRAMING OUTLINE

FujiFilm X-T20 Specifications

General

Megapixels	24.3 MP
ISO Range	200-12800 (expandable to 100-51200)
Continuous Shooting Speed	8 fps
Weight	383 g (including battery and memory card)
Image Processor	X-Processor Pro
Wireless Connectivity	Wi-Fi
Battery	NP-W126S Li-ion battery
Dimensions	118.4 x 82.8 x 41.4 mm
Sensor	APS-C X-Trans CMOS III
Autofocus Points	91 points
Screen	3.0-inch tilting LCD (1.04M dots)
Viewfinder	0.39-inch OLED (2.36M dots)
Video Resolution	4K at 30 fps, Full HD at 60 fps
Battery Life	Approx. 350 shots
Shutter Speed	1/4000 sec to 30 sec
