3
Rack Configuration and Installation
This section explains the configuration and installation of this rack, handling
procedures, and the rack connection procedure.
3.1 Configuration
This section provides the specifications of the 19-inch rack and its accessories.
3.1.1 Model 2724
*1) Ensure that the floor load based on the total rack capacity does not exceed the floor strength
(withstand load) at the installation site (such as an office).
*2) Key operation is required for locking the door handle.
Item Specifications
Product name 19-inch rack Model 2724 base rack
Type name 19R-272A2
Appearance Coated black (front and rear doors with punched metal finish)
Unit mounting capacity 24 U
Size (W x D x H) [mm] 700 x 1050 x 1200
Maximum weight-bearing
load [kg]
Total rack capacity: 571 kg (*1)
Total load capacity: 480 kg (excluding rack)
Rack: 91 kg
Door opening ratio 80%
Accessories
Items already attached to the rack when shipped
・ Front door, rear door, and a pair of side covers
Items in their own packages when shipped with the rack
・ Rack door key: 2 (*2)
・ Cable holder (front): 6
・ Cable holder (rear): 6
・ M5 flat head screw and core spring nut: 12 of each (for cable holder)
・ Cage nut tool
・ User's Guide (CD): 1 set
To Next Page
