4 Handling the Rack after Installation 181
E
4.11 Attaching a Stabilizer (Pullout Type)
The procedure for attaching the stabilizer (pullout type) is shown below.
■ Confirm the components, and prepare the necessary tools.
Confirm that all components have been delivered (see the table below).
Also, prepare the necessary tools:
・ Phillips screwdriver (No. 2 bit): For M5 flat head screws
The procedure for attaching the stabilizer (pullout type) is shown below.
4.11.1 Attaching the stabilizer (pullout type)
1 From the front, insert the stabilizer body under the rack.
Stabilizer (pullout type) Type name: 19R-26FS2
Product name Quantity
Stabilizer bodyf 1
Mounting plate 1
M5 flat head screw 6
Hexagon wrench (6 mm) 1
Stabilizer body
(Front)
