4 Handling the Rack after Installation 157
E
4.5 Mounting a General-purpose Table
(Movable Type)
■ Confirming components
Confirm that all components have been delivered (see the table below).
Also, prepare the necessary tools:
・Phillips screwdrivers (No. 3 bits)
・Cage nut tool
The procedure for mounting a general-purpose table (movable type) is as follows:
1. Insert cage nuts.
2. Attach rear brackets.
3. Mount the table.
General-purpose table (movable type)
Type name: 19R-26TR2
Component name Quantity
Table 1
Rear bracket L 1
Rear bracket R 1
M6 cage nut 8
M5 cage nut 2
M6 screw 12
Belt 2
Installation Guide 1
To Next Page
