Fujitsu AB*G14LVTA User Manual

- (02 - 10) -
OUTDOOR UNIT AO

G14-18L2
OUTDOOR UNIT AO

G14-18L2
MODEL: AO
 
G18L2
Cooling
z
Combination
of Indoor Unit
COOLING OPERATION
Cooling Capacity
Input Power
(min-max)
EER
Seasonal Data
Room 1 Room 2
Total Capacity
(min-max)
Pdesign
SEER
Energy
Efciency
Class
kW kW kW kW kW
2 Room
7 7 2.10 2.10 4.20 ( 1.7 - 5.2 ) 1.24 ( 0.35 - 1.68 ) 3.39 4.2 7.0 A++
7 9 2.10 2.50 4.60 ( 1.7 - 5.3 ) 1.26 ( 0.35 - 1.79 ) 3.65 4.6 6.8 A++
7 12 1.90 3.10 5.00 ( 1.7 - 5.6 ) 1.55 ( 0.35 - 1.95 ) 3.23 5.0 6.5 A++
7 14 1.80 3.20 5.00 ( 1.8 - 5.7 ) 1.55 ( 0.40 - 1.99 ) 3.23 5.0 6.5 A++
9 9 2.50 2.50 5.00 ( 1.7 - 5.6 ) 1.56 ( 0.35 - 1.95 ) 3.21 5.0 6.6 A++
9 12 2.10 2.90 5.00 ( 1.7 - 5.7 ) 1.55 ( 0.35 - 1.95 ) 3.23 5.0 6.5 A++
9 14 2.00 3.00 5.00 ( 1.8 - 5.8 ) 1.55 ( 0.40 - 1.99 ) 3.23 5.0 6.4 A++
12 12 2.50 2.50 5.00 ( 1.7 - 5.8 ) 1.56 ( 0.35 - 1.99 ) 3.21 5.0 6.4 A++
Heating
z
Combination
of Indoor Unit
HEATING OPERATION
Heating Capacity
Input Power
(min-max)
COP
Seasonal Data
Room 1 Room 2
Total Capacity
(min-max)
Pdesign
SCOP
Energy
Efciency
Class
kW kW kW kW kW
2 Room
7 7 2.70 2.70 5.40 ( 1.8 - 6.0 ) 1.24 ( 0.50 - 1.61 ) 4.37 3.8 4.1 A+
7 9 2.50 3.00 5.50 ( 1.8 - 6.0 ) 1.36 ( 0.50 - 1.87 ) 4.04 4.0 4.1 A+
7 12 2.30 3.30 5.60 ( 1.8 - 6.1 ) 1.38 ( 0.50 - 1.88 ) 4.06 4.2 4.0 A+
7 14 2.25 3.35 5.60 ( 1.9 - 6.2 ) 1.35 ( 0.55 - 1.86 ) 4.15 4.2 4.0 A+
9 9 2.80 2.80 5.60 ( 1.8 - 6.1 ) 1.41 ( 0.50 - 1.90 ) 3.97 4.2 4.1 A+
9 12 2.45 3.15 5.60 ( 1.8 - 6.2 ) 1.38 ( 0.50 - 1.88 ) 4.07 4.2 4.0 A+
9 14 2.35 3.25 5.60 ( 1.9 - 6.3 ) 1.35 ( 0.55 - 1.86 ) 4.15 4.2 4.0 A+
12 12 2.80 2.80 5.60 ( 1.8 - 6.3 ) 1.34 ( 0.50 - 1.84 ) 4.18 4.2 4.0 A+
Notes:
7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h,14:14000Btu/h models.

•
The above is the value for connecting with Wall Mounted type.

•
2 or more indoor units should be connected.

•
Cooling capacity is based on 27 °CDB / 19 °CWB (indoor temperature), 35 °CDB (outdoor temperature).

•
Heating capacity is based on 20 °CDB (indoor temperature), 7 °CDB / 6 °CWB (outdoor temperature).

•
Pipe length :5m, Height difference :0m. (Outdoor unit to indoor unit)

•
The total capacity of connected a indoor unit is up to 24000 Btu from 14000 Btu.

•
Where "14" means "

•
Wall Mounted type" only models. Other types of indoor units can not be connected.
