OUTDOOR UNIT AO

G18-24L3
OUTDOOR UNIT AO

G18-24L3
DIMENSIONS2.
MODEL

: AO

G18L3, AO

G24L3
(Unit : mm)
INSTALLATION PLACE

600 or more
250 or more
250 or more
300 or more
600 - 1000
100 or more
300 or more
100 - 300
250 or more
(Service space)
When there are obstacles at the
back or front sides.
When there are obstacles at
the back, side(s), and top.
When there are obstacles at the
back, side with the installation of
more than one unit.
114
228
57
12
94
41
Top view
Front view
Side view
900
700
21
9
40 31 12330
400
Bottom view
370
650
Ø12
Drain cap mounting places Drain pipe mounting places

If the space is larger that is stated, the condition will be the same as that are no obstacles.
