MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
SYSTEM DIAGRAM

1 remote controller
z
z
2 remote controllers
Primary Secondary
A B C
Indoor unit Indoor unit
Remote controller Remote controllers
A , B , C : Remote controller cable.
A
<
=
500m ; B+C
<
=
500m
ELECTRICAL WIRING

1 remote controller
z
z
2 remote controllers
Indoor unit
REMOTE
CONTROLLER
1 2 3
1 2 3
Primary
Secondary
Indoor unit
1 2 3
1 2 3 1 2 3
REMOTE
CONTROLLER
Remote controller Remote controllers
1 (RED) : 12V
2 (WHITE) : Signal
3 (BLACK) : COM
DIMENSIONS

83.5
15.3
63.5
Hole
45.3
4.54.5
4.5
9
12.5
Hole x 2
Hole x 3
6
30 33.5
23
120
120
(120)
18
Front View Side View Rear View
[Unit : mm]
