- (01-02) -
MULTI TYPE
2, 3, 4 ROOMS TYPE
MULTI TYPE
2, 3, 4 ROOMS TYPE
SLIM DUCT TYPE1-1-2.
MODELS : AR
G07LLTA, AR
G09LLTA, AR
G12LLTA,
AR
G14LLTA, AR
G18LLTA,
AR
G12LLTB, AR
G14LLTB, AR
G18LLTB
FEATURES
Slim design and wide range of static
pressure for exible installation.
Slim design
z
The slim design allows installations
where ceilings are narrow.
Height
Drain pump built-in
198mm
Drain port
Drain pump
Compact design
z
Condensate lift-up to 850mm.
Drain hose is standard accessory
Selectable wide range of static
z
pressure
By using a DC fan motor, it is possible to
change static pressure range from 0 to
90Pa. The change of static pressure range
is possible by remote controller.
0
[Pa]
Airflow rate
Static pressure range
[m
3
/h]
90
Air - intake
z
Air intake direction can be selected to
match the installation site.
Bottom side Back side
Flexible installation
z
Ceiling concealed
Wall concealed
Filter (Accessory)
z
Filter : 2pcs.
To Next Page
