Fujitsu AB*G14LVTA User Manual

- (02 - 09) -
OUTDOOR UNIT AO

G14-18L2
OUTDOOR UNIT AO

G14-18L2
CAPACITY TABLE5.
COMBINATIONS5-1.
MODEL

: AO

G14L2
Cooling
z
Combination
of Indoor Unit
COOLING OPERATION
Cooling Capacity
Input Power
(min-max)
EER
Seasonal Data
Room 1 Room 2
Total Capacity
(min-max)
Pdesign
SEER
Energy
Efciency
Class
kW kW kW kW kW
2 Room
7 7 2.00 2.00 4.00 ( 1.4 - 4.4 ) 1.09 ( 0.35 - 1.40 ) 3.67 4.0 6.7 A++
7 9 1.95 2.05 4.00 ( 1.4 - 4.4 ) 1.09 ( 0.35 - 1.40 ) 3.67 4.0 6.6 A++
7 12 1.65 2.35 4.00 ( 1.4 - 4.6 ) 1.05 ( 0.35 - 1.47 ) 3.81 4.0 6.5 A++
9 9 2.00 2.00 4.00 ( 1.4 - 4.5 ) 1.09 ( 0.35 - 1.43 ) 3.67 4.0 6.6 A++
9 12 1.70 2.30 4.00 ( 1.4 - 4.7 ) 1.05 ( 0.35 - 1.47 ) 3.81 4.0 6.5 A++
Heating
z
Combination
of Indoor Unit
HEATING OPERATION
Heating Capacity
Input Power
(min-max)
COP
Seasonal Data
Room 1 Room 2
Total Capacity
(min-max)
Pdesign
SCOP
Energy
Efciency
Class
kW kW kW kW kW
2 Room
7 7 2.20 2.20 4.40 ( 1.1 - 5.4 ) 1.03 ( 0.25 - 1.78 ) 4.27 3.8 4.1 A+
7 9 2.15 2.25 4.40 ( 1.1 - 5.4 ) 1.03 ( 0.25 - 1.78 ) 4.27 3.8 4.1 A+
7 12 1.95 2.45 4.40 ( 1.1 - 5.5 ) 1.02 ( 0.25 - 1.76 ) 4.31 3.8 4.0 A+
9 9 2.20 2.20 4.40 ( 1.1 - 5.4 ) 1.03 ( 0.25 - 1.78 ) 4.27 3.8 4.0 A+
9 12 2.00 2.40 4.40 ( 1.1 - 5.5 ) 1.02 ( 0.25 - 1.76 ) 4.31 3.8 4.0 A+
Notes:
7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h models.

•
The above is the value for connecting with Wall Mounted type.

•
2 or more indoor units should be connected.

•
Cooling capacity is based on 27 °CDB / 19 °CWB (indoor temperature), 35 °CDB (outdoor temperature).

•
Heating capacity is based on 20 °CDB (indoor temperature), 7 °CDB / 6 °CWB (outdoor temperature).

•
Pipe length :5m, Height difference :0m. (Outdoor unit to indoor unit)

•
The total ability of connected a indoor unit is up to 21000 Btu from 14000 Btu.

•

Fujitsu AB*G14LVTA Specifications

General

Brand	Fujitsu
Model	AB*G14LVTA
Category	Air Conditioner
Language	English
