Maintenance Menu
5. After tension is applied to the fiber, the following message will be shown:
Press the UP key to move the cleaving blade near the fiber. The final adjustment
will performed by the machine, so the initial blade position does not have to be
precise.
6. Press the SET key to start adjustment. The blade position will be adjusted
automatically by the cleaver.
7. After the fiber is cleaved, the clamps will release automatically. Remove the fiber
and press the SET key to apply the adjusted position. To abandon the adjustment,
press ESC key.
¾ The movement may require a long time depending on the starting
position of the cleaving blade.
¾ The blade moves very slowly during adjustment.
¾ Make sure that the cleaving blade does not hit the fiber.
