Fujitsu LifeBook P702 Operating Manual

Removing and installing components
during servicing
Removing a cover
1
2
► Remove the screw (1).
Keep the screws in a safe place. If you are removing m ore than one component at
the sam e time, store the screws for the individual componen ts separate from each
other. If you install the wrong screws, components may be damaged.
► Lift the cover off the notebook (2).
Removing memory modules
3
2
1
1
► Carefully push the two mounting
clips outwards (1).
MemoryexpansionMemorymodule

The memory module snaps upwards (2).
► Pull the memory module out of its slot
in the direction of the arrow (3).
Fujitsu Technology Solutions 65

Fujitsu LifeBook P702 Specifications

General

Resolution	1280 x 800
Graphics	Intel HD Graphics 4000
Processor	Intel Core i5
CPU	Intel Core i5-3320M
RAM	DDR3
Storage	320 GB HDD
Display	12.1-inch LED Backlit
Operating System	Windows 7 Professional
Ports	USB 3.0, VGA, Ethernet, SD card reader
Wireless	Wi-Fi 802.11 a/b/g/n, Bluetooth 4.0
