- WLAN Specifications
WLAN Specifications
Specifications
Item Specification
Type of network
The integrated Intel Centrino Advanced-N 6200 (802.11agn 2x2) and Atheros
XSPAN 801.11bgn devices conform to IEEE 802.11a, 802.11b/g, and 802.11n, Wi-
Fi based*.
Transfer rate (Automatic switching) 54 Mbps maximum data rate (IEEE802.11n to be determined)
Active frequency
• 802.11n: 2.4 GHz or 5 GHz
• 802.11b/g: 2400~2473 MHz
• 802.11a: 4900 ~ 5850 MHz
Typical operating distances**
• 802.11a: 40 ft. (12 m) @ 54 Mbps; 300 ft. (91 m) @ 6 Mbps
• 802.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft. (91 m) @ 1 Mbps
• 802.11g: 100 ft. (30 m) @ 54 Mbps; 300 ft. (91 m) @ 1 Mbps
• 802.11n: Estimated double the operating distance of 802.11g and 802.11a in their
respective frequencies.
Number of channels
• 802.11a: 8 independent channels
• 802.11b/g: 11 channels, 3 non-overlapping channels
• 802.11n:
2.4 GHz - 3 non-overlapping channels when Channel Bonding is not used; 2 non-
overl
apping channels when Channel Bonding is used.
5 GHz - 12 non-overlapping UNII channels with or without Channel Bonding
Security
Encryption Types - WEP, TKIP, AES***, WPA 1.0, WPA 2.0, CCX compliant
Maximum recommended
number of computers to be
connected over wireless LAN
(during ad hoc connection)
10 units or less ****
