75
- Using Express/PC Cards
Figure 32. Installing/Removing Express Cards or PC Cards
Using Express/PC Cards
Depending upon your system configuration, your LIFEBOOK notebook supports either ExpressCards or
PC Cards, both of which can perform a variety of functions depending on which type of card you install.
There are two different width ExpressCards: 34 mm and 54 mm. The connector inside the Express Card
slot is located on the left-hand side of the slot. If you insert a 34 mm card, be sure to align it with the left
side of the slot when inserting it.
PC Cards are one size only. The connector in the PC Card slot is locted in the center of the slot.
For further information, refer to the instructions supplied with your card(s).
