U41629-J-Z156-2-76 Options Guide 21
Preparation Floorstand model
4.1.3 Removing the hard disk cover
The hard disk cover has to be removed before installing further hard disk drives:
Ê Terminate all applications and shut down the server correctly.
Ê If your operating system has not switched off the sever, press the on/off
switch.
Figure 5: Removing the hard disk cover
Ê Unlock the server (1) and remove the key.
Ê Push the drive cover up as far as possible (2).
Ê Remove the hard disk cover (3 + 4).
1
2
4
3
