36 Options Guide U41629-J-Z156-2-76
Installing a 3.5-inch floppy disk drive Accessible drives
6.3 Installing a 3.5-inch floppy disk drive
Zwischen dem Festplattenkäfig und den 5,25-Zoll-Einbauplätzen befindet sich
ein 3,5-Zoll-Einbauplatz für das optionale Diskettenlaufwerk.
Ê Open the server and remove the front cover or rack front cover as described
in the chapter “Preparation” on page 19 et seqq..
Ê From the inside press out the 3.5-inch dummy cover on the front cover.
V CAUTION!
Keep the dummy cover for future use. If you remove the accessible
drive again and do not replace it with a new one, the dummy cover
must be reinstalled to comply with EMC regulations and to satisfy
cooling requirements and fire protection measures.
Figure 19: Removing the floppy disk drive holder
Ê Remove the two screws (1) that attach the drive holder to the housing front.
Ê Pull on the drive holder and completely remove it from the server (2).
1
2
