Specifications for iX500
The following table summarizes the specifications of the ScanSnap.
Item Specification
Product name ScanSnap iX500
Scanning method Automatic Document Feeder (ADF), simultaneous duplex scanning
Scanning color mode Simplex/duplex, color/gray/black and white/auto (automatic color,
gray, and B&W detection)
Optical system/image sensor Equal-magnification optics/color CIS × 2 (front × 1, back × 1)
Light source 3 color LED (Red/Green/Blue)
Scanning speed (A4 portrait)
Automatic resolution/normal/better/best
25 sheets/minute
Excellent
7 sheets/minute
Scan area Refer to "Documents to Scan (iX500)" (page 212)
Document thickness
Number of sheets allowed to be loaded Up to 50 sheets
A4: 80 g/m
2
(20 lb)
Interface USB USB 3.0 (*1)/USB 2.0/USB 1.1 (connector: B type)
Wireless LAN (*2) IEEE802.11b/g/n compliant
Input power Voltage 100 to 240 V ±10%
Phase Single phase
Frequency range 50/60 Hz
Power consumption USB connection During operation: 20 W or less
During sleep mode: 1.6 W or less
Wireless LAN
connection
During operation: 20 W or less
During sleep mode: 2.5 W or less
Temperature/humidity
allowable ranges
Temperature During operation: 5 to 35 degrees C/41 to 95 degrees F
During standby: -20 to 60 degrees C/-4 to 140 degrees F
During storage/transportation: -20 to 60 degrees C/-4 to 140 degrees
F
Humidity During operation: 20 to 80%
During standby: 8 to 95%
During storage/transportation: 8 to 95%
Outer dimensions (Width × Depth × Height) Min.: 292 × 159 × 168 mm/11.50 × 6.26 × 6.61 in. (when the ADF
paper chute (cover) is closed)
Max.: 292 × 484 × 293 mm/11.50 × 19.06 × 11.54 in. (when the ADF
paper chute (cover) is open and the extension is extended)
Weight 3.0 kg (approx. 6.62 lb)
Environmental specification Compliant with the International Energy Star Program, and RoHS
Directive
Specifications of the ScanSnap
504
