Accessories for your Tablet PC (opti
onal)
Your docking cradle (optional)
As well as fast charging, your docking cradle is a device that also allows you to quickly connect
your Tablet PC to your peripherals such as a monitor, keyboard, mouse, etc. You only need
to dock the Tablet PC to be able to work with your peripheral devices.
Cradle components
PortsPortsCradle
1
2
3
4
5
10
6
8
9
7
1 = Dock release button
2 = Docking port
3=USBport 3.0
4=USBport 3.0
5=USBport 3.0
6 = VGA monitor port
7 = HDMI Port
8 = LAN port
9 = Security Lock device
10 = DC jack socket (DC IN)
With STYLISTIC Q508 the LAN port of the cradle supports Wake-on-LAN (G3 only).
With STYLISTIC
Q508 two additional external monitors can be connected
either to the VGA monitor port or to the HDMI Port of the docking cradle. The
simultaneous use of two external monitors is supported. (see "
Screen resolutions
for integrated screen and external screens", Page 75)
Fujitsu 39
