3.2 Transducer Setting (FCV-1500 only)
Select the type of transducer used as follows:
Automatic selection of transducer
1. Select TRANSDUCER SETTING from the SYSTEM menu and press the [MENU] key.
(Refer to page 3-1 for how to display the SYSTEM menu.)
[TRANSDUCER SETTING]
XDR SELECT : TYPE MANUAL
LO-FREQ HI-FREQ
FREQUENCY : ---kHz --- kHz
TRANSDUCER : --- ---
OUTPUT POWER : --W --W
SUPPLY VOLTAGE : --V -- V
IMPEDANCE : --Ω --Ω
FACTORY SETTING : YES NO
(Select 'YES' & Press [MENU] to default setting.
<Valid for this page>
[▲] [▼] : Select item.
[t] [s] : Change setting. (or [+], [-])
[MENU] : Return to SYSTEM MENU.
Warning: Changing power settings can damage
your transducer! Please confirm your
transducer's power and frequency rating.
)
CAUTION
Confirm type of transducer used before
setting type on the menu.
Wrong transducer setting may damage the
transducer and void the warranty.
For using SURFACE on the TARGET
ECHO menu, the surface-use 1 kW
transducer should be connected.
Use of it with another transducer may
result in damage to the transducer.
Figure 3-2 TRANSDUCER SETTING menu
2. Select TYPE.
3. Select LO-FREQ or HI-FREQ with the arrow keys.
4. Set transducer frequency with [+]/[-] key.
5. Press [▼] to select the TRANSDUCER field.
To Next Page
