2. HOW TO SETUP THE MENU
19
2.8 [System Information] Tab (SCX-20/SCX-21 Only)
The [System Information] tab shows the system information of the SATELLITE COMPASS
™
.
Note: The [System Information] tab is not used in the SC-33. You can open the tab, however all
contents are grayed out and cannot be adjusted.
How to show the system information
Click the [Get Information] button to show the system information.
*: Grayed out when the SCX-21 is connected.
Item Remarks
Main PCB Main board version number
Starter Ver. Program version number for the starter program
Booter1 Ver. Program version number for the booter 1 program
Booter2 Ver. Program version number for the booter 2 program
App. Ver. Program version number for the application program
Serial No Serial number
GNSS 1 to GNSS 4 Version information for GNSS 1 to GNSS 4
CAN Unique Number* CAN unique ID for the NMEA2000 network
CAN Address* CAN address for the NMEA2000 network
Powered Time
Operating time from when the SATELLITE COMPASS
™
is turned on.
Overall Powered
Time
Total operating time from the first time SATELLITE COMPASS
™
is started.
