GNSS Setup Disable SV GPS (Off, 1 to 32)
Disable All (Unchecked)
GLONASS (Off, 1 to 24)
Disable All (Unchecked)
Galileo (Off, 1 to 36)
Disable All (Unchecked)
QZSS (Off, 193 to 197)
Disable All (Unchecked)
SV ELEV (5 to 90°; 5°)
SBAS Mode (On, Off)
Search (Auto, Manual)
Satellite Selection (120 to 138; 120)
Disable SBAS (Off, 120 to 128)
Disable All (Unchecked)
Sensor Setup Sensor HDG (-180.0° to 180.0°; 0.0°)
Offset* Roll (-10.0° to 10.0°; 0.0°)
Pitch (-10.0° to 10.0°; 0.0°)
SOG/3-Axis Speed (-12.5 to 12.5%; 0.0%)
Air Pressure (-99.9 to 99.9 hPa; 0.0 hPa)
Air Temperature (-99.9 °C to 99.9 °C; 0.0 °C)
Dimensions/
Equipment Identification (Not used.)
CCRP* Ship’s Width (1.0 to 999.9 m; 3.0 m)
Ship’s Length (1.0 to 999.9 m; 10.0 m)
Ship’s Height (1.0 to 999.9 m; 5.0 m)
A
NT Position X0 (Set
ting range depends on the ship’s information.; 0.00 m)
ANT Position Y0 (Setting range depends on the ship’s information.; 5.0 m)
ANT Position Z0 (Setting range depends on the ship’s information.; 2.5 m)
CALC-SPD-POSN Y1 (Setting range depends on the ship’s information.
;
0.0 m)
CALC-SPD-POSN Y2 (Setting range depends on the ship’s information.
;
10.0 m)
CALC-SPD-POSN Z (Setting range depends on the ship’s information.
;
0.0 m)
Sensor HDG (0 to 9999 s; 5 s)
Smoothing 3-Axis Speed (0 to 9999 s; 5 s)
ROT (0 to 30 s; 2 s)
DR Time (1 to 5 min; 5 min)
PGN Setup* 065280 (Heave) (Off, 20, 25, 50, 100, 200, 1000, 2000 msec)
126992 (System Time) (Off, 1000, 2000 msec)
126993 (Heartbeat) (Off, 60000 msec)
127250 (Vessel Heading) (Off, 20, 25, 50, 100, 200, 1000, 2000 msec)
127251 (Rate of Turn) (Off, 20, 25, 50, 100, 200, 1000, 2000 msec)
127252 (Heave) (Off, 20, 25, 50, 100, 200, 1000, 2000 msec)
127257 (Attitude) (Off, 20, 25, 50, 100, 200, 1000, 2000 msec)
127258 (Magnetic Variation) (SC-33: Off, 100, 1000, 2000 msec;
SCX-20: Off, 1000, 2000 msec)
129025 (Position, Rapid Update) (Off, 100, 200, 1000, 2000 msec)
129026 (COG, SOG, Rapid Update) (Off, 200, 250, 1000, 2000 msec)
129029 (GNSS Position Data) (Off, 1000, 2000 msec)
129539 (GNSS DOPs) (Off, 1000, 2000 msec)
129540 (GNSS Sats in View) (Off, 1000, 2000 msec)
130310 (Environmental Parameters) (SC-33: Off, 500, 1000, 2000;
SCX-20: Off, 500, 1000, 2000)
130312 (Temperature) (Off, 1000, 2000 msec)
130314 (Actual Pressure) (Off, 1000, 2000 msec)
[SC_Setting_Tool] dialog box
Default settings are
shown in bold italic.
*: Setting is required at
installation.
To Next Page
