190-02692-00 Rev. A
Garmin G1000 Pilot’s Guide for the Piper PA-32 Saratoga
99
ENGINE INDICATION SYSTEM
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
1
Manifold Pressure Displays engine manifold pressure inches of mercury (IN HG).
Turbocharged Aircraft – Maximum manifold pressure range displayed in red.
2
Tachometer Displays engine tachometer in revolutions per minute (RPM).
3
Fuel Quantity Displays left (L) and right (R FUEL QTY) fuel quantity in gallons (GAL).
4
Fuel Flow Displays fuel flow in gallons per hour (gph)
5
Turbine Inlet Temperature Displays Turbine Inlet Temperature in degrees Fahrenheit (°F).
6
Exhaust Gas Temperature Displays Exhaust Gas Temperature in degrees Fahrenheit (°F).
7
Cylinder Head Temperature Displays Cylinder Head Temperature in degrees Fahrenheit (°F).
