A white arrow before the VRP identifier indicates the selected VRP. Up to eleven VRPs are visible at a time.
If there are more than can be shown, the list can be scrolled. If there are no VRPs in the list, text indicating
that there are no nearest VRPs is displayed. If there are no nearest VRPs in the list, the information is dashed.
Figure 5-39 NRST – NEAREST VRP Page
Nearest VRP
VRP Information
– VRP Name
– Country
– Lat/Long
VRP Identifier/Symbol
– Bearing/Distance to VRP
from aircraft position
USER WAYPOINTS
The system can create and store up to 1,000 user-defined waypoints. User waypoints can be created from
any map page (except PFD Inset Map, AUX-TRIP PLANNING Page, or Procedure pages) by selecting a position
on the map using the Joystick, or from the WPT – USER WPT INFORMATION Page by referencing a bearing/
distance from an existing waypoint, bearings from two existing waypoints, or latitude and longitude. Once a
waypoint has been created, it can be renamed, deleted, or moved. Temporary user waypoints are erased upon
system power down.
