ZOOM RANGE ON THE NAVIGATION MAP
Stormscope lightning data can be displayed up to 800 nm zoom range (in North Up orientation) on the
MAP - NAVIGATION MAP Page. However, in Track Up orientation at the 500 nm range, a portion of Stormscope
lightning data can be behind the aircraft and therefore not visible on the Navigation Map . Since the range for
Stormscope data is 400 nm diameter total (200 nm in front and 200 nm behind), the 500 nm range in North
Up orientation shows all the data.
At a map range of less than 25 nm, Stormscope lightning data is not displayed, but can still be present.
The maximum zoom range can also be set on the Navigation Map. Note that Stormscope data above the
selected maximum zoom range is decluttered.
Selecting a Stormscope range on the Navigation Map:
1) Press the MENU Key.
2) Select ‘Map Setup’.
3) Select the ‘Weather’ group.
4) Press the ENT Key.
5) Turn the large FMS Knob to select ‘STRMSCP SMBL’.
6) Turn the small FMS Knob to select the maximum display range.
7) Press the ENT Key.
8) Push the FMS Knob to return to the MAP - NAVIGATION MAP Page.
To change the display range on the MAP - NAVIGATION MAP Page, turn the Joystick clockwise to zoom
out or counter-clockwise to zoom in.
