SYSTEM OVERVIEW
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
The main page groups are navigated using the FMS Knob; specific pages within each group can vary depending
on the configuration of optional equipment.
Selecting a page using the FMS Knob:
1) Turn the large FMS Knob to display the list of page groups; continue turning the large FMS Knob until the
desired page group is selected.
2) Turn the small FMS Knob to display the desired page within a specific page group.
There are also several pages (e.g., Airport Information pages) which are selected first from within a main page
group with the FMS Knobs, then with the appropriate softkey at the bottom of the page. In this case, the page
remains set to the selected screen until a different screen softkey is pressed.
Page Group Pages within Page Group
MAP • Navigation Map
• Traffic Map
• Stormscope (optional)
• Weather Data Link (optional)
• Terrain
WPT (Waypoint)
• Airport/Procedures/Weather Information Pages
- Airport Information (INFO-1 Softkey)
- Airport Directory Information (INFO-2
Softkey)
- Departure Information (DP Softkey)
- Arrival Information (STAR Softkey)
- Approach Information (APR Softkey)
- Weather Information (optional) (WX Softkey)
• Intersection Information
• NDB Information
• VOR Information
• VRP Information
• User Waypoint Information
AUX (Auxiliary)
• Trip Planning
• Weight and Fuel Planning
• Utility
• GPS Status
• System Setup
• XM Pages (optional)
- XM Information (Info Softkey)
- XM Radio (Radio Softkey)
• System Status
FPL (Flight Plan)
• Active Flight Plan
- Wide View, Narrow View (View Softkey)
• Flight Plan Catalog
- Stored Flight Plan (via New Softkey)
NRST (Nearest) • Nearest Airports
• Nearest Intersections
• Nearest NDB
• Nearest VOR
• Nearest VRP
• Nearest User WPTS
• Nearest Frequencies
• Nearest Airspaces
Table 1-5 Page Groups and Pages
The procedure loading pages may be accessed at any time on the MFD by pressing the PROC Key. A menu
is initialized, and when a departure, approach, or arrival is selected, the appropriate procedure loading page is
opened. These pages can also be accessed from the active and stored flight plan pages. Turning the FMS Knob
does not scroll through the procedure loading pages.
