If the traffic unit fails, an annunciation as to the cause of the failure is shown in the center of the MAP -
TRAFFIC MAP Page. During a failure condition, the Operating Mode cannot be selected.
MAP - TRAFFIC MAP Page
Annunciation
Description
NO DATA Data is not being received from the traffic unit
DATA FAILED Data is being received from the traffic unit, but the unit is self-reporting a failure
FAILED Incorrect data format received from the traffic unit
Table 6-28 Traffic Failure Annunciations
The annunciations to indicate the status of traffic information appear in a banner at the lower left corner of
maps on which traffic can be displayed.
Traffic Status Banner Annunciation Description
TA OFF SCALE
A Traffic Advisory is outside the selected display range*.
Annunciation is removed when traffic comes within the selected display range.
TA X.X ± XX ↕
System cannot determine bearing of Traffic Advisory**.
Annunciation indicates distance in nm, altitude separation in hundreds of feet, and
altitude trend arrow (climbing/descending).
TRFC FAIL
Traffic system has failed (unit is self-reporting a failure or sending incorrectly
formatted data)
NO TRFC DATA Data is not being received from the traffic system.
*Shown as symbol on MAP - TRAFFIC MAP Page
**Shown in center of MAP - TRAFFIC MAP Page
Table 6-29 Traffic Status Annunciations
