190-02692-00 Rev. A
Garmin G1000 Pilot’s Guide for the Piper PA-32 Saratoga 375
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
The MAP - NAVIGATION MAP Page Setup Menu also controls the display of traffic. The setup menu
controls the map range settings. Traffic data symbols and labels can be decluttered from the display. If a
map range larger than the map range setting is selected, the data is removed from the map. Maps besides the
Traffic Map Page use settings based on those selected for the MAP - NAVIGATION MAP Page.
The PFD can display traffic on either the inset navigation map or a traffic inset map. The traffic inset map
resembles the Traffic Map Page and is shown in a heading-up orientation.
Displaying traffic information on the PFD inset maps:
1) Press the INSET Softkey.
2) Press the TRAFFIC Softkey to display traffic information on the PFD inset navigation map (TRFC-1).
3) Press the TRFC-1 Softkey to display the traffic-only inset (TRFC-2).
4) Press the TRFC-2 Softkey to remove traffic information from the PFD inset navigation map.
