190-01639-00 GSU 75 ADAHRS Installation Manual
Rev. 6 Page 2-2
2.3 Equipment Available
Each of the accessories listed in Table 2-4 are available separately for the GSU 75.
Each of the accessories listed in Table 2-4 are available separately for the GMU 44.
Table 2-7 shows the contents of the GTP 59 Outside Air Temperature (OAT) Probe kit (011-00978-00).
The GTP probe has an attached pigtail.
Table 2-4 GSU 75 Accessories
Item Garmin Catalog Part Number
GSU 75 Unit Rack 117-00608-00
GSU 75 Connector Kit 011-03109-00
Table 2-5 GMU 44 Accessories
Item Garmin Catalog Part Number
Sub Assy, Connector Kit, GMU 44 011-00871-00
Installation Rack, GMU 44 115-00481-00
Installation Rack, Modified, GMU 44 115-00481-10
Table 2-6 Contents of GSU 75 Connector Kit (011-03109-00)
Item Garmin Number Quantity
Configuration Module w/EEPROM, Jackscrew 011-00979-20 1
50/78 pin Backshell w/Hardware, Jackscrew 011-01855-04 1
Heat Shrink Tubing, FEP, .093 ID 312-00005-05 6
78 pin High Density D-Sub Connector Male, Str, Military Crimp,
Sealed, w/Ground Indents
330-00776-78 1
22D Military Crimp Contact Pins 336-00021-00 77
Table 2-7. Contents of GTP 59 OAT Probe Kit (011-00978-00)
Item Description Garmin Part Number
Nut Nut, 5/16”, Hex, Skirt 210-00055-00
Screw, Qty. (2) Screw, 4-40 x .250, PHP, SS/P, w/NYL 211-60234-08
Washer Washer, Lock, Self-Sealing, 5/16 212-00026-00
Contact Pins, Qty. (5) Contact, Pin, Mil Crimp, Size 22D 336-00021-00
GTP 59 OAT Probe Outside Air Temperature Sensor 494-00022-xx
