190-01639-00 GSU 75 ADAHRS Installation Manual
Rev. 6 Page 3-2
Non-Garmin part numbers shown are not maintained by Garmin and consequently are
subject to change without notice.
Extracting the #18 and #20 contact requires that the expanded wire barrel be cut off from
the contact. It may also be necessary to push the pin out from the face of the connector
when using an extractor due to the absence of the wire. A new contact must be used when
reassembling the connector.
Table 3-3 GSU 75 Recommended Crimp Tools
Manufacturer
Hand Crimping
Tool
18-20 AWG 22-28 AWG
Positioner
Insertion/
Extraction Tool*
Positioner
Insertion/
Extraction
Tool
Military P/N M22520/2-01 N/A M81969/1-04 M22520/2-09 M81969/1-04
Positronic 9507 9502-11 M81969/1-04 9502-4 M81969/1-04
AMP 601966-1 N/A 91067-1 601966-6 91067-1
Daniels AFM8 K774 M81969/1-04 K42 M81969/1-04
Astro 615717 N/A M81969/1-04 615725 M81969/1-04
*Extracting the #18 and #20 contact requires that the expanded wire barrel be cut off from the contact. It
may also be necessary to push the pin out from the face of the connector when using an extractor due to
the absence of the wire. A new contact must be used when reassembling the connector.
Table 3-4 GMU 44 Recommended Crimp Tools
Manufacturer Hand Crimping Tool
22-24 AWG
Positioner
Insertion/Extraction
Tool
Military P/N M22520/2-01 M22520/2-08 M81969/1-02
Positronic 9507 9502-5 M81969/1-02
AMP 601966-1 601966-5 91067-2
Daniels AFM8 K13-1 M81969/1-02
Astro 615717 615724 M81969/1-02
