GE Multilin D60 Line Distance Protection System D-3
APPENDIX D D.1 IEC 60870-5-103
D
 <22> Local parameter setting
 <23> Characteristic 1
 <24> Characteristic 2
 <25> Characteristic 3
 <26> Characteristic 4
 <27> Auxiliary input 1
 <28> Auxiliary input 2
 <29> Auxiliary input 3
 <30> Auxiliary input 4
Supervision indications in monitor direction
INF Semantics
 <32> Measurand supervision I
 <33> Measurand supervision V
 <35> Phase sequence supervision
 <36> Trip circuit supervision
 <37> I>> back-up operation
 <38> VT fuse failure
 <39> Teleprotection disturbed
 <46> Group warning
 <47> Group alarm
Earth fault indications in monitor direction
INF Semantics
 <48> Earth fault L
1
 <49> Earth fault L
2
 <50> Earth fault L
3
 <51> Earth fault forward, meaning line
 <52> Earth fault reverse, meaning busbar
Fault indications in monitor direction
INF Semantics
 <64> Start/pick-up L
1
 <65> Start/pick-up L
2
 <66> Start/pick-up L
3
 <67> Start/pick-up N
 <68> General trip
 <69> Trip L
1
 <70> Trip L
2
 <71> Trip L
3
 <72> Trip I>> (back-up operation)
 <73> Fault location X in ohms
 <74> Fault forward/line
