GE iBox User Manual

GE Grid Solutions
iBox/iBox Kit
Installation and Maintenance Guide
GE Information
994-0047-5.10-4
157
Appendix E: DPA Default Point Mapping
For point mapping of individual standard iBox kits, please look in the Source column of the table below. Point mapping
corresponding to Plant I/O applies to all types of standard iBox kits.
DCA DPA
Source
Data
Type
MODBUS DCA
Register
Address
Point Description
COM1 COM2
DNP DPA
Point
MODBUS DPA
Point Address
DNP TCP/IP
DPA Point
Plant I/O
DI
N/A
iBox
Digital Input #1
0
1 0
N/A
iBox
Digital Input #2
1
2 1
N/A
iBox
Digital Input #3
2
3 2
N/A
iBox
Digital Input #4
3
4 3
N/A
iBox
Digital Input #5
4
5 4
N/A
iBox
Digital Input #6
5
6 5
N/A
iBox
Digital Input #7
6
7 6
N/A
iBox
Digital Input #8
7
8 7
DO
N/A
iBox
Digital Output #1
0
9 0
N/A
iBox
Digital Output #2
1
10 1
N/A
iBox
Digital Output #3
2
11 2
N/A
iBox
Digital Output #4
3
12 3
DNP DCA
(IBOX-BSC and IBOX-LAN)
DI
N/A
Digital Input #1 on DNP DCA
8
13 8
N/A
Digital Input #2 on DNP DCA
9
14 9
N/A
Digital Input #3 on DNP DCA
10
15 10
N/A
Digital Input #4 on DNP DCA
11
16 11
N/A
Digital Input #5 on DNP DCA
12
17 12
N/A
Digital Input #6 on DNP DCA
13
18 13
N/A
Digital Input #7 on DNP DCA
14
19 14
N/A
Digital Input #8 on DNP DCA
15
20 15
DO
N/A
Digital Output #1 on DNP DCA
4
21 4
N/A
Digital Output #2 on DNP DCA
5
22 5
N/A
Digital Output #3 on DNP DCA
6
23 6
N/A
Digital Output #4 on
DNP DCA
7
24 7
