GE SF6 User Manual

Installation
Connection the vacuum pump
GE Information08- 2016 L31- 853EN/04
1/4
Presentation
Necessary
Grid Solutions tools
List of the Grid Solutions tools necessary for the installing :
Mark Diagram Designation Number
(1)
VACUUM PUMP
(OPTIONAL)
110/220 V 50 Hz (4.5 m
3
/h)
or
115/230 V 60 Hz (4.5 m
3
/h)
1
(2)
UNIVERSAL CONNECTION
1/2” GAZ ET 1/2” NPT
1
In this module
This module contains the following topics :
Topic Page
Installing the universal connection 2
Connection the tube of the customer supply vacuum pump 3
Connection the Grid Solutions supply vacuum pump 4
