Installation
Installation of terminals
with p reparation o f con t act surfaces
GE Information08- 2016 L31- 512EN/03
4/4
Installing terminals
Process
Assemble immediately
the terminals (1) on the interrupting chambers (2) after
preparation of contact surfaces. Fasten the terminals using screws (3); use
CONTACT GREASE to seal the screws.
x4
HM12-45
5daN.m
3
2
2
2
1
Comment
D The electrical resistance value of the assembly should be :
R 2
D Before installing H.V. connectors, prepare the contact surfaces in the
same way.
