- 13 -
Hardware Installation
1-3 System Block Diagram
PCIe4.0 x16
PCIe x16 slot
(rear side)
PCIe4.0 x16
PCIe4.0 x16
PCIe4.0 x16
PCIe x16 slot
(rear side)
PCIe4.0 x16
PCIe4.0 x16
4 x PCIe x16 slots (
support 4 x SW GPUs)
PCIe switch
Broadcom
Riser Card
4 x PCIe x16 slots (
support 4 x SW GPUs)
PCIe switch
Broadcom
Riser Card
4 x PCIe x16 slots (
support 4 x SW GPUs)
PCIe switch
Broadcom
Riser Card
4 x PCIe x16 slots (
support 4 x SW GPUs)
PCIe switch
Broadcom
Riser Card
8-Channel DDR4, 12 x DIMMs
Speed up to 3200 MHz
8-Channel DDR4, 12 x DIMMs
Speed up to 3200 MHz
DMI3 x 4
PCIe3.0
x
1
PCIe3.0
x
4
eSPI
SPI
1 x USB 2.0
SPI Flash
64 MB
4 x SSATAIII
8 x SATAIII
2 x USB 3.0
(rear)
USB 3.0 x2
TPM
VGA
COM
(Internal)
ASPEED
AST2600
BMC
MLAN
MAC
SPI Flash
64 MB
3 x UPI 11.2GT/s
PCH
Lewisburg-R
Intel C621A
Intel
X710-AT2
10/100/1G
PHY
PCIe4.0
x
8PCIe4.0
x
8
Ice Lake-SP
LGA4189 (Socket P+)
CPU1
2 x 10G
BASE-T LAN
Ice Lake-SP
LGA4189 (Socket P+)
CPU0
4-bay 2.5” NVMe/SATA +
4-bay 2.5” SATA
4 x Slimline 4i
3 x Slimline 4i
