- 27 - System Hardware Installation
3-4 Removing and Installing the Fan Duct
Follow these instructions to remove/install the fan duct:
1. Remove the two screws securing the fan ducts.
2. Lift up to remove the fan ducts
3. To install the fan duct, align the fan duct with the guiding groove. Push down the fan duct into
chassis until its rmly seats, then install the four screws to secure the fan ducts in place.
1
1
