- 39 - System Hardware Installation
3-12 Replacing Power Distribution Board Cage
Before you remove or install the power distribution board cage:
• Make sure the system is not turned on or connected to AC power.
2
Follow these instructions to remove the power distribution board cage:
1. Loosen and remove the four screws securing the cage.
2. While holding the cage, slide the cage to the front of the system and remove the cage in the
direction of the arrow.
To Next Page
