35
10 Electrical Connection
WARNING: This appliance must be earthed.
This appliance must be wired in accordance with these
instructions. Any fault arising from incorrect wiring cannot be
put right under the terms of the Glow-worm guarantee.
All system components must be of an approved type.
Electrical components have been tested to meet the
equivalent requirements of the BEAB.
Do not interrupt the mains supply with a time switch or
programmer.
Connection of the whole electrical system and any heating
system controls to the electrical supply must be through a
common isolator.
Isolation should preferably be by a double pole switched
fused spur box having a minimum contact separation of
3mm on each pole. The fused spur box should be readily
accessible and preferably adjacent to the boiler. It should be
identified as to its use.
10.1 Installer Interface
Gain access to the Installer Interface by removing the
securing screw, see diagram 10.1.
Remove the cable securing clip which will release the Installer
Interface cap, see diagram 10.1.
Release the cable gland, route the mains and system cables
through the strain relief and connect to the relevant plug
dependant upon your choice of system controls, see diagram
10.2.
10.2 Electrical Connections - Testing
Carry out preliminary electrical system checks as below:
1. Test insulation resistance to earth of mains cables.
2. Test the earth continuity and short circuit of cables.
3. Test the polarity of the mains.
IMPORTANT NOTE
ALL electrical connections to the boiler
must be permanently fixed to a wall or a
sturdy support feature in a tidy manner.
