Technical Data
312001B 27
Technical Data
MAGNUM ProX7 MAGNUM ProX9
Working pressure range 0-3000 psi
(0-21 MPa, 0-207 bar)
0-3000 psi
(0-21 MPa, 0-207 bar)
Electric motor 5.8A
(open frame,
permanent magnet DC)
9.4A
(open frame,
permanent magnet DC)
Operating horsepower 3/4 7/8
Maximum delivery (with tip) 0.31 gpm (1.17 lpm) 0.38 gpm (1.44 lpm)
Paint hose 1/4 in. x 50 ft
(6.4 mm x 15 m)
1/4 in. x 50 ft
(6.4 mm x 15 m)
Maximum tip hole size
0.017 in. (0.43 mm) 0.019 in. (0.48 mm)
Weight, sprayer only 43 lb (20 kg) 43 lb (20 kg)
Weight, sprayer, hose & gun 46 lb (21 kg) 46 lb (21 kg)
Dimensions (Upright):
Length 23.75 in. (60.32 cm) 23.75 in. (60.32 cm)
Width 17.5 in. (44.45 cm) 19.25 in. (48.89 cm)
Height 36.5 in. (92.71 cm) 36.5 in. (92.71 cm)
Dimensions (Folded):
Length 23.25 in. (59.05 cm) 23.25 in. (59.05 cm)
Width 17.5 in. (44.45 cm) 19.25 in. (48.89 cm)
Height 22.00 in. (55.88 cm) 22.00 in. (55.88 cm)
Power cord 16 AWG, 3-wire, 6 ft (1.8 m)
Fluid inlet fitting 3/4 in. internal thread (standard garden hose thread)
Fluid outlet fitting 1/4 NPSM external thread
Inlet screen (on suction tube) 35 mesh (450 micron)
Wetted parts, pump & hose stainless steel, brass, leather, ultra-high molecular weight
polyethylene (UHMWPE), carbide, nylon, aluminum, PVC,
polypropylene, fluroelastomer
Wetted parts, gun aluminum, brass, carbide, nylon, plated steel, stainless steel,
UHMWPE, zinc
Generator requirement 1500 Watt minimum
Electrical power requirement 120 Vac, 60 Hz, 15A, 1 phase
Storage temperature range ◆❖ -30° to 160°F (-35° to 71°C)
Operating temperature range ✔ 40° to 115°F (4° to 46°C)
◆ When pump is stored with non-freezing fluid. Pump damage will occur if water or latex paint freezes in pump.
❖ Damage to plastic parts may result if impact occurs in low temperature conditions.
✔ Changes in paint viscosity at very low or very high temperatures can affect sprayer performance.
