EN - 13
See Figure 4 and Figure 5 for all controls and
features locations.
IGNITION KEY
See Figure 6.
Controls power to the engine. The key cannot
be removed when in on position.
CHOKE CONTROL KNOB
See Figure 7.
Controls air intake to the engine.
THROTTLE CONTROL LEVER
See Figure 8.
Controls engine speed.
POWER TAKE-OFF (PTO)
SWITCH
See Figure 9.
Controls power to mower blades. The engine
will not start with the PTO switch in the on
position.
OPERATOR PRESENCE LEVER
See Figure 10.
Operator presence lever MUST be engaged
to operate drive control grip or PTO. Engine
will stop if operator presence lever is not
engaged when parking brake is released.
WARNING: AVOID INJURY.
Read and understand the Safety
section before proceeding.
Figure 7
Choke Off
Choke On
Figure 9
PTO /
Blades Off
PTO /
Blades On
