EN - 18
6. Lift bypass levers up slightly and push
into operating position.
TRANSPORT UNIT
1. Raise deck to highest cutting height. See
Set Cutting Height on page 15.
2. Move unit to transport vehicle.
3. Engage parking brake.
4. Stop engine and remove key.
5. Secure mower frame to transport vehicle.
NOTICE: NEVER secure unit to vehicle from
rods or linkages that could be damaged.
Proper maintenance can prolong the life of
unit. The Maintenance Schedule on Page 19
shows the recommended service schedule.
Your Gravely dealer can provide service and
adjustments to keep your unit operating at
peak efficiency. Contact an authorized engine
manufacturer’s service center for engine
service.
More frequent service may be required due to
working conditions (heavy loads, high
ambient temperatures, dusty conditions, or
airborne debris).
See the maintenance instructions in the
Engine Manual for additional information.
SERVICE POSITION
See Figure 19.
1. Move unit to a flat, level surface.
2. Place drive control grip in neutral position
and engage parking brake.
3. Stop engine and remove key.
4. Wait for all moving parts to stop and for
hot parts to cool.
5. Disconnect negative battery cable from
battery.
6. Chock wheels. Strap and clamp unit onto
lift, if used.
Bypass Position
(Transaxles
Disengaged)
Operating Position
(Transaxles
Engaged)
Figure 18
MAINTENANCE
WARNING: AVOID INJURY.
Read and understand the Safety
section before proceeding.
