Gree VERSATI III Series Service Manual

Unit Control
3 Controller
3.1 General
(This picture is just for reference)
This display panel uses the capacitor touch screen for input operation. The valid touching area
indicates the black rectangle when the display panel lights off.
This control panel is of high sensitivity and will response to unexpected click by the foreign matters on
the display panel. Therefore, please keep it clean during operation.
3.1.1 Menu Page
1
2
3
4 5 6 7 8
9
Above the menu, the corresponding icon will be displayed based on the mode and status of the
controller.
Press Button

Gree VERSATI III Series Specifications

General

Type	Air to Water Heat Pump
Series	VERSATI III
Refrigerant	R32
Operating Temperature Range (Cooling)	10°C to 48°C
Heating Capacity	4.0 - 16.0 kW
Cooling Capacity	4.0 - 14.0 kW
COP	Up to 4.5 (A7/W35)
EER	3.2 - 4.3
Power Supply	220-240V, 50Hz
