21
MAINTENANCE
Frequently examine the E-DRIVE installation for imbalance and signs of wear or damage to cables, springs and mounting. Do not use
if repair or adjustment is necessary. Power must be turned off before servicing, cleaning or adjusting the opener.
Certain mechanical aspects of the installation must be checked at regular intervals.
Monthly
• Examine the installation for imbalance and signs of wear or damage to cables, springs and mounting. Do not use if repair or
adjustment is necessary
• Check chain alignment, tension and condition. Adjust / replace if required
• Check PE / IR beam/s and bump edge functionality where applicable
Quarterly
• Check tightness of fixing bolts and (sprocket) grub screws. Adjust if required.
• Check correct electrical operation.
• Check manual operation via hand chain.
• Lubricate the drive chain.
• Check door balance. The drive chain should display a transition of tension from one side of the linkage to the other in the lower half
of the roller door travel. This transition is the ‘balance’ point. Adjust if required.
• Conduct door maintenance in accordance with door manufactures guidelines. This will include door balance.
NOTE: SERVICE MUST BE CARRIED OUT BY A QUALIFIED TECHNICIAN
To view total cycles (limits must be set)
• Drive to door to closed limit.
• Press and hold CLOSE for 10 seconds.
• After 10 seconds and while still holding CLOSE, press and release the SET button.
• Status LED will light up indicating number of cycles performed.
To read number of cycles, follow the ‘Reading Status Flashes’ routine described below.
Reading Status Flashes
• STATUS indicator will start flashing to signify the value of the least significant digit of the overall number. A solidly lit indicator
stands for zero.
• Press set to view the next digit.
• Continue previous step until the STATUS indicator flashes quickly for 1 second then goes out. This signifies that the entire number
has been displayed.
To reset error
(This process indicates there has been a severe problem. Persistent resetting will void warranty and may damage the door and/or
opener). This procedure will only work when the status light is flashing 4, 5, 9, 10, 14 or 15 times.
• Hold the STOP button for 10 seconds
• While still holding the STOP button, press and release the SET button
The STATUS indicator should flash quickly for 1 second. Any errors that were flashing should have stopped.
WARNING
MECHANICAL
Power MUST be turned off before servicing or adjusting the opener. Disconnect the supply when cleaning!
